Enhancement of the immunogenicity of influenza A virus by the inhibition of immunosuppressive function of NS1 protein


The truncation of the nonstructural NS1 protein is a novel approach for the generation of immunogenic attenuated influenza viruses. However, the innate immune mechanisms that cause the increased immunogenicity of influenza viruses with altered NS1 proteins are poorly understood. The goal of this study was to compare the immune responses in mice immunized with two variants of the influenza A/Puerto Rico/8/1934 (A/PR8) virus: the wild type virus (А/PR8/full NS) and the variant with the NS1 protein shortened to 124 amino acid residues (А/PR8/NS124). The investigated parameters of immunity included cytokine production, the dynamic variation of the innate immune cell populations, and the rate of the influenza-specific T-cell responses. An intraperitoneal route of immunization was chosen due to the variability in the replication capacity of the investigated viruses in the respiratory tract. The levels of interferon β (IFNβ), tumor necrosis factor α (TNFα), monocyte chemo-attractant protein 1 (MCP1), interleukin 6 (IL6), and IL27 in peritoneal washings of mice immunized with А/PR8/NS124 were significantly higher compared to the mice immunized with the wild-type virus. The А/PR8/NS124 treated group showed a delayed attraction of monocytes and neutrophils as well as a more pronounced reduction in the percentage of dendritic cells in the peritoneal cavity. The expression level of the CD86 activation marker on the cells expressing the molecules of the major histocompatibility complex II (MHCII+) was significantly higher in mice immunized with А/PR8/NS124 than in the group immunized with А/PR8/full NS. Finally, immunization with А/PR8/ NS124 led to an increased formation of influenza-specific CD8+ effector T-cells characterized by the simultaneous production of IFNγ, IL2, and TNFα. We hypothesize that elevated cytokine production, enhanced dendritic cell migration, and increased CD86 expression on antigen-presenting cells upon immunization with А/PR8/NS124 lead to a more effective presentation of viral antigens and, therefore, promote an increased antigen-specific CD8+ immune response.

About the Authors

K. A. Vasilyev
Smorodintsev Research Institute of Influenza
Russian Federation

Kirill Vasilyev

St. Petersburg

M. A. Yukhneva
Smorodintsev Research Institute of Influenza
Russian Federation
St. Petersburg

A.-P. S. Shurygina
Smorodintsev Research Institute of Influenza
Russian Federation
St. Petersburg

M. A. Stukova
Smorodintsev Research Institute of Influenza
Russian Federation
St. Petersburg

A. Y. Egorov
Smorodintsev Research Institute of Influenza; University of Natural Resources and Life Sciences
Russian Federation

St. Petersburg

Vienna, Austria


1. Steel J, Lowen AC, Pena L, Angel M, Solórzano A, Albrecht R, Perez DR, García-Sastre A, Palese P. Live attenuated influenza viruses containing NS1 truncations as vaccine candidates against H5N1 highly pathogenic avian influenza. J Virol 2009; 83(4), 1742-53. doi: 10.1128/JVI.01920-08.

2. Wacheck V, Egorov A, Groiss F, Pfeiffer A, Fuereder T, Hoeflmayer D, Kundi M, Popow-Kraupp T, RedlbergerFritz M, Mueller CA. A novel type of influenza vaccine: safety and immunogenicity of replication-deficient influenza virus created by deletion of the interferon antagonist NS1. J Infect Dis 2010; 201(3), 354-62. doi: 10.1086/649428.

3. Ferko B, Stasakova J, Sereinig S, Romanova J, Katinger D, Niebler B, Katinger H, Egorov A. Hyperattenuated recombinant influenza A virus nonstructural-protein-encoding vectors induce human immunodeficiency virus type 1 Nef-specific systemic and mucosal immune responses in mice. J Virol 2001; 75(19), 8899-908. doi: 10.1128/JVI.75.19.8899-8908.2001.

4. Ferko B, Stasakova J, Romanova J, Kittel C, Sereinig S, Katinger H, Egorov A. Immunogenicity and protection efficacy of replication-deficient influenza A viruses with altered NS1 genes. J Virol 2004; 78(23), 13037- 45. doi: 10.1128/JVI.78.23.13037-13045.2004.

5. Quinlivan M, Zamarin D, García-Sastre A, Cullinane A, Chambers T, Palese P. Attenuation of equine influenza viruses through truncations of the NS1 protein. J Virol 2005; 79(13), 8431-9. doi: 10.1128/JVI.79.13.8431-8439.2005.

6. Richt JA, Lekcharoensuk P, Lager KM, Vincent AL, Loiacono CM, Janke BH, Wu W-H, Yoon K-J, Webby RJ, Solórzano A. Vaccination of pigs against swine influenza viruses by using an NS1-truncated modified live-virus vaccine. J Virol 2006; 80(22), 11009-18. doi: 10.1128/JVI.00787-06.

7. Vincent AL, Ma W, Lager KM, Janke BH, Webby RJ, García-Sastre A, Richt JA. Efficacy of intranasal administration of a truncated NS1 modified live influenza virus vaccine in swine. Vaccine 2007; 25(47), 7999-8009. doi: 10.1016/j.vaccine.2007.09.019.

8. Zhou H, Zhu J, Tu J, Zou W, Hu Y, Yu Z, Yin W, Li Y, Zhang A, Wu Y. Effect on virulence and pathogenicity of H5N1 influenza A virus through truncations of NS1 eIF4GI binding domain. J Infect Dis 2010; 202(9), 1338-46. doi: 10.1086/656536.

9. Baskin CR, Bielefeldt-Ohmann H, Tumpey TM, Sabourin PJ, Long JP, Garcia-Sastre A, Tolnay AE, Albrecht R, Pyles JA, Olson PH, Aicher LD, Rosenzweig ER, Murali-Krishna K, Clark EA, Kotur MS, Fornek JL, Proll S, Palermo RE, Sabourin CL, Katze MG. Early and sustained innate immune response defines pathology and death in nonhuman primates infected by highly pathogenic influenza virus. Proc Natl Acad Sci USA 2009; 106(9), 3455-60. doi: 10.1073/pnas.0813234106.

10. Stukova MA, Sereinig S, Zabolotnyh NV, Ferko B, Kittel C, Romanova J, Vinogradova TI, Katinger H, Kiselev OI, Egorov A. Vaccine potential of influenza vectors expressing Mycobacterium tuberculosis ESAT-6 protein. Tuberculosis 2006; 86(3-4), 236-46. doi: 10.1016/

11. Iwasaki A, Pillai PS. Innate immunity to influenza virus infection. Nat Rev Immunol 2014; 14(5), 315- 328. doi: 10.1038/nri3665.

12. Tripathi S, White MR, Hartshorn KL. The amazing innate immune response to influenza A virus infection. Innate Immun 2015; 21(1), 73-98. doi: 10.1177/1753425913508992.

13. Haye K, Burmakina S, Moran T, García-Sastre A, Fernandez-Sesma A. The NS1 protein of a human influenza virus inhibits type I interferon production and the induction of antiviral responses in primary human dendritic and respiratory epithelial cells. J Virol 2009; 83(13), 6849-62. doi: 10.1128/JVI.02323- 08.

14. Tisoncik JR, Billharz R, Burmakina S, Belisle SE, Proll SC, Korth MJ, García-Sastre A, Katze MG. The NS1 protein of influenza A virus suppresses interferonregulated activation of antigen-presentation and immune-proteasome pathways. J Gen Virol 2011; 92(9), 2093-104. doi: 10.1099/vir.0.032060-0.

15. Reading PC, Whitney PG, Pickett DL, Tate MD, Brooks AG. Influenza viruses differ in ability to infect macrophages and to induce a local inflammatory response following intraperitoneal injection of mice. Immunol Cell Biol 2010; 88(6), 641-50. doi: 10.1038/icb.2010.11.

16. Council NR. Guide for the care and use of laboratory animals. Washington, DC: National Academy Press; 2010.

17. Reed LJ, Muench H. A simple method of estimating fifty per cent endpoints. Am J Epidemiol 1938; 27(3), 493-7. doi: 10.1093/oxfordjournals.aje.a118408.

18. Misharin AV, Morales-Nebreda L, Mutlu GM, Budinger GRS, Perlman H. Flow cytometric analysis of macrophages and dendritic cell subsets in the mouse lung. Am J Respir Cell Mol Biol 2013; 49(4), 503-10. doi: 10.1165/rcmb.2013-0086MA.

19. Yu X, Xie J. Roles and underlying mechanisms of ESAT- 6 in the context of Mycobacterium tuberculosis–host interaction from a systems biology perspective. Cell Signal 2012; 24(9), 1841-6. doi: 10.1016/j.cellsig.2012.05.014.

20. Stasakova J, Ferko B, Kittel C, Sereinig S, Romanova J, Katinger H, Egorov A. Influenza A mutant viruses with altered NS1 protein function provoke caspase-1 activation in primary human macrophages, resulting in fast apoptosis and release of high levels of interleukins 1β and 18. J Gen Virol 2005; 86(1), 185-95. doi: 10.1099/vir.0.80422-0.

21. Talon J, Horvath CM, Polley R, Basler CF, Muster T, Palese P, García-Sastre A. Activation of interferon regulatory factor 3 is inhibited by the influenza A virus NS1 protein. J Virol 2000; 74(17), 7989-96. doi: 10.1128/JVI.74.17.7989-7996.2000.

22. Guo Z, Chen L, Zeng H, Gomez JA, Plowden J, Fujita T, Katz JM, Donis RO, Sambhara S. NS1 protein of influenza A virus inhibits the function of intracytoplasmic pathogen sensor, RIG-I. Am J Respir Cell Mol Biol 2007; 36(3), 263-9. doi: 10.1165/rcmb.2006-0283RC.

23. Kohlmeier JE, Woodland DL. Immunity to respiratory viruses. Annu Rev Immunol 2009; 27, 61-82. doi: 10.1146/annurev.immunol.021908.132625.

24. McGill J, Heusel JW, Legge KL. Innate immune control and regulation of influenza virus infections. J Leukoc Biol 2009; 86(4), 803-12. doi: 10.1189/jlb.0509368.

25. Cruz JLG, Pérez-Girón JV, Lüdtke A, GómezMedina S, Ruibal P, Idoyaga J, Muñoz-Fontela C. Monocyte-derived dendritic cells enhance protection against secondary influenza challenge by controlling the switch in CD8+ T-cell immunodominance. Eur J Immunol 2017; 47(2), 345-52. doi: 10.1002/eji.201646523.

26. Pulendran B, Maddur MS. Innate immune sensing and response to influenza. In: Influenza Pathogenesis and Control. Volume II. Springer; 2014, p. 23-71.

27. Lim K, Hyun Y-M, Lambert-Emo K, Capece T, Bae S, Miller R, Topham DJ, Kim M. Neutrophil trails guide influenza-specific CD8+ T cells in the airways. Science 2015; 349(6252), aaa4352. doi: 10.1126/science.aaa4352.

28. Leliefeld PHC, Koenderman L, Pillay J. How neutrophils shape adaptive immune responses. Front Immunol 2015; 6, 471. doi: 10.3389/fimmu.2015.00471.

29. McNab F, Mayer-Barber K, Sher A, Wack A, O’garra A. Type I interferons in infectious disease. Nat Rev Immunol 2015; 15(2), 87-103. doi: 10.1038/nri3787.

30. Manicassamy B, Manicassamy S, Belicha-Villanueva A, Pisanelli G, Pulendran B, García-Sastre A. Analysis of in vivo dynamics of influenza virus infection in mice using a GFP reporter virus. Proc Natl Acad Sci 2010; 107(25), 11531-6. doi: 10.1073/pnas.0914994107.

31. Legge KL, Braciale TJ. Accelerated migration of respiratory dendritic cells to the regional lymph nodes is limited to the early phase of pulmonary infection. Immunity 2003; 18(2), 265-77. doi: 10.1016/S1074-7613(03)00023-2.

32. Yewdell JW, Haeryfar SMM. Understanding presentation of viral antigens to CD8+ T cells in vivo: the key to rational vaccine design. Annu Rev Immunol 2005; 23, 651-82. doi: 10.1146/annurev. immunol.23.021704.115702.

33. Schweitzer AN, Borriello F, Wong RC, Abbas AK, Sharpe AH. Role of costimulators in T cell differentiation: studies using antigen-presenting cells lacking expression of CD80 or CD86. J Immunol 1997; 158(6), 2713-22. PubMed PMID: 9058805.

34. Lechmann M, Berchtold S, Steinkasserer A, Hauber J. CD83 on dendritic cells: more than just a marker for maturation. Trends Immunol 2002; 23(6), 273-5. doi: 10.1016/S1471-4906(02)02214-7.

35. Seder RA, Darrah PA, Roederer M. T-cell quality in memory and protection: implications for vaccine design. Nat Rev Immunol 2008; 8(4), 247-58. doi: 10.1038/nri2274.


For citations:

Vasilyev K.A., Yukhneva M.A., Shurygina A.S., Stukova M.A., Egorov A.Y. Enhancement of the immunogenicity of influenza A virus by the inhibition of immunosuppressive function of NS1 protein. Microbiology Independent Research Journal (MIR Journal). 2018;5(1):36-47. (In Russ.)
